THE GRINDER
SPECIFICATION:
Motor: Brushless DC
Voltage: 110-220 v
Dual voltage for international use
RPM: 4500 RPM
Torque: 57 oz/in (0.4 N/m)
Max Horsepower: 1/6 HP
50-60 HZ
Weight: 6 kg
Box Size:
48.25 cm W x 36.75 cm H x 18.75 cm D
Threaded, open-tip spindle for 1/4″ and 1/8″ jewelry bit attachment
Low profile, Contemporary Design
Vibration Control
Industry’s Best Warranty
Accessories:
Super-brite LED Light Strip
Lens-grade Eye Shield
Removable Water Tray
Guide Track
Accessory Drawer
EZ-View Windows
Stainless Steel Bit Guard
Universal Quick-Fit Bit System
Splash Curtain
Power & Light Switch
Additional assessors:
Grid Scraper
Aqua Flow System and Brush
Lumishield Mount Cap
THE GRINDER is equipped with a 6 ft. (1.8 m) durable and removable 3-prong cord which meets international standards and is 110-220 VAC compatible.
Mini G Elevated Work Surface
The secondary platform with water reservoir can be effortlessly placed atop the main grid enabling use of 1/4″ and 1/8″ spindle top bits. Equipped with its own reservoir, the secondary platform has water ingeniously delivered to the grinding head for flawless execution.
- Platform Dimensions: 1.3”H x 6”W x 5”D (33 x 153 x 127 cm)
- Elevated surface outfitted with EZ-Lift Gri
Removable Water Tray
Unlike other grinders, the water reservoir comes equipped with a removable tray which can be easily emptied after use. With handles on each side, the lift-out tray makes cleanup simple and safe. Eliminate carrying a heavy awkward grinder to the sink or potentially spilling its contents on floors and work surfaces. Any accumulated glass grit can be cleaned out with the included
Accessory Drawer and Tray Insert –
An exclusive, compartmentalized, and built-in drawer is a space saving way to store spare bits, included scraper, Aqua Flow System, replacement brushes, stainless steel bit guards, and other tools!
Water Wave Stabilizer
& Support System
The uniquely designed main grid has incorporated supports and baffles on the underside to stabilize work surface and limit water movement during tray transport.
EZ-View Windows & Lift Grid
It’s important to keep a sufficient flow of water to the bit head while grinding. Reservoir water level can be continuously monitored through the EZ-View Windows. The Lift Grid easily removes for addition of water or cleaning with the smartly-designed cutouts.
EZ-Guide Channels
THE GRINDER is equipped with convenient channels located on each side of the working surface for attaching tools.
Everwear Bit Guard
Made from durable stainless steel, bit guard allows interchangeable usage of ¾” and 1″ grinding bit sizes.
The Guard®
The Guard is a wear resistant splash curtain designed to keep the studio clean and dry. The Guard is a wear resistant, flexible material that detaches easily for cleaning. Glass pieces of unlimited size and length can easily slide through the bristles which capture debris and return water to the reservoir.
The LumiShield®
The Lumishield is an illuminated, lens-grade eye shield which can be easily attached. This high visibility shield provides protection from minute glass particles that become airborne and casts an even amount of light across the work surface area. It is equipped with an energy efficient, super-brite LED light strip to best illuminate the project you are working on.
